1.6 Ton Electric Forklift

Characteristics of electric forklifts

1. Electric forklifts have steel gantry frames, which have stronger load-bearing capacity and stability compared to traditional C-shaped gantry frames

2. Increase by 45% after lifting. High power and high-quality batteries, using 3 replaceable batteries, fast charging, long-lasting and durable

3. Electric forklifts have a hydraulic steering system, which is easy to operate, has high stability, and saves electricity

Efficient and multifunctional display screen, displaying working time and battery voltage

4. Equipped with high-power AC motors, with high power, no need to replace carbon brushes, maintenance free, energy-saving and efficiency enhancing

Contact Now E-Mail Telephone WhatsApp

Product Details

Our strengths

(1) Our electric forklift is equipped with imported controllers from world-renowned brands. After professional adjustments, the walking and upgrading control is accurate and efficient, with excellent performance. Forklifts have functions such as regenerative braking, ramp braking, and fault self diagnosis.

(2) Electric forklifts adopt a dynamic load sensing priority steering system, which provides faster steering response and smoother driving.

(3) Advanced H-type remote drive unit, compact structure, lower center of gravity, more reasonable layout, and more stable driving.

(4) Electric forklifts can fully open the engine hood and can be quickly removed from both sides. Hinge design frame side door. Adopting advanced battery replacement design concepts, providing quick and convenient maintenance.

Electric Forklift

Model	CPD12	CPD16	CPD20	CPD25	CPD30	CPD50	CPD70
Power form	Electric	Electric	Electric	Electric	Electric	Electric	Electric
load（kg）	1200	1600	2000	2500	3000	5000	600
Load center distance(mm)	500	500	500	500	500	500	500
Wheelbase(mm)	1380	1500	1600	1680	1820	2080	2480
Driving wheel(mm)	2X/2	2X/2	2X/2	2X/2	2X/2	2X/2	4X/2
Drive wheel track width(mm)	920	960	960	960	1010	1120	1300
Steering wheel track width(mm)	910	910	950	950	1000	1100	1300
Free lifting height (mm)	110	100	100	100	/	100	100
Seat height(mm)	1050	1050	1060	1100	1200	1208	1208
Vehicle length(mm)	3170	3370	3380	3620	3770	4020	4820
Overall width(mm)	1100	1100	1100	1120	1300	1320	1860
Fork size(mm)	40X80X1070	40X100X1070	40X122X1070	40X122X1070	40X122X1070	55X150X1220	60X150X1220
Minimum ground clearance(mm)	110	110	120	120	120	140	150
Turning radius(mm)	2080	2200	2300	2475	2475	2750	2800
Drive control type	AC	AC	AC	AC	AC	AC	AC
Noise level(dB (A))	70	70	70	70	75	75
