1.8T Excavator

The first thing that grabs your attention is undoubtedly the color. A black 1.8-ton mini excavator exudes an air of sophistication and power that traditional yellow or white excavators don't quite achieve. The sleek, modern look of these machines adds a touch of professionalism to any construction site.

Contact Now E-Mail Telephone WhatsApp

Product Details

Product detail

Model	YCW-18	Operating Weight	1800kg
Bucket capacity	0.04cbm	Max Digging Radius	3900mm
Maximum Digging Height	3540mm	Maximum Digging Depth	2310mm
Rated Speed	0-3.5km/h	Hydraulic Cylinder Brand	Japan brand
Hydraulic Pump Brand	Nachi	Hydraulic Valve Brand	Italy brand
Engine Brand	Yanmar/kubota	Power	10kw
MOQ	1 Set	Warranty	1 Year

Model	YCW-08	YCW-10(HOT)	YCW-12(HOT)	YCW-15/16
Operating weight	800 kg	950 kg	1100 kg	1380 kg
Rated power	12hp/(3600rpm)	8.2 KW/rpm	8.2kw/rpm	18.1kw
Engine	Koop 192FA	Koop 192FA	Koop 192FA Kubota D722	Changchai EV80 Yanmar/Kubota
Bucket capacity	0.02 m³	0.022 m³	0.022 m³	0.030 m³
Max.digging radius	2650 mm	2850 mm	2850 mm	3370 mm
Max.digging depth	1200 mm	2000 mm	1655 mm	1600 mm
Max.digging height	2470 mm	2580 mm	1745 mm	2850 mm
Max.dumping height	1600mm	1750mm	1750mm	1800mm
Overall width	720 mm	860 mm	950 mm	1050 mm

Model	YCW-17S	YCW-20S(HOT)	YCW-25S	YCW-35S
Total Weight	1550 kg	1920 kg	2480 kg	3375kg
Rated Power	11.8 kw/rpm	11.8kw/rpm	15 kw/rpm	20.5 kW/rpm
Engine	Yanmar/Kubota	Yanmar/Kubota	Yanmar3TNV76-P	Yanmar3TNV88-P
Bucket Capacity	0.040m³	0.040m³	0.066 m³	0.09 m³
Maximum Digging Distance	3500 mm	3600 mm	4200 mm	4965 mm
Max. Digging Depth	2120 mm	2310 mm	2320 mm	2880 mm
Max. Digging Height	3310 mm	3540 mm	3540 mm	4600mm
Gradeability	58(30°)	58(30°)	58(30°)	58(30°)
Overall Width	1100 mm	990/1240 mm	1300/1500 mm	1300/1500 mm

All accessories are available here.

Support Multi-Function Operation,
Cabin,Air conditioning,Swing boom , Telescopic crawler track function can be optional.

Use our Quick coupler(quick hitch) can add the attachment tools like: driller auger, hydraulic breaker hammer, trailer,
20cm--100cm bucket, rake,gripper, wood grab and so on.

Mini excavator is designed for small works,small projects,in garden,farmland,
municipal works,vegetable greenhouse,
digging trench. small engine, simple design, easy to operate and maintain.
